JL Audio 98103

OEM Integration DSP with Automatic Time Correction and Digital EQ 8-ch. Inputs / 4-ch. Stereo + 2 Subwoofer RCA Outputs The FiX™ 86 is a state-of-the-art digital signal processor engineered to deliver outstanding sound from factory source units, while retaining OEM fader control. Unlike typical OEM interface products, the FiX™ 86 automatically corrects time-delayed factory outputs prior to signal summing and EQ correction. Calibration takes just a single button press and about 30 seconds to complete, with no special equipment needed. With a powerful 24-bit DSP processor and quad 1/3 octave equalizers onboard, complex factory signals, up to 3-way front and 2-way rear, are combined and level matched automatically into six, full-range stereo signals: Front (fader-controlled), Rear (fader-controlled) and Subwoofer (non-fading, front+rear summed) outputs. Differential-balanced inputs accept virtually any OEM analog audio signal, from low-voltage, line-level to highpower, amplified speaker-level outputs (up to 30V RMS). Activation methods include 12-volt or Auto Turn-On (Signal/DC-Offset Sensing) to trigger a dedicated remote turn-on output for aftermarket equipment. An optional DRC-100 or DRC-200 Digital Remote Controller (sold separately) adds Master Volume Control, Subwoofer Level Control and preserves hands-free calling features, all from the driver’s seat. Achieving great sound from your factory stereo has never been easier, or sounded better... Now with fader retention and subwoofer output!

General Specifications

• Power Supply Type: Regulated DC-DC SMPS
• Input Operating Voltage: 10 - 16 VDC
• Standby Current Draw: <1.5 mA
• Operating Current Draw: 0.7 A
• Recommended Fuse Value: 1 A
• Input Channels: Eight
• Input Type: Differential-Balanced
• Input Voltage Range: 250 mV - 30 V RMS
• Minimum Input Voltage: 10 mV RMS
• Input Level Setting: Fully automatic
• Output Channels: Six (Front/Rear/Sub Output Pairs)
• Analog Output: Unbalanced, stereo RCA jacks
• Digital Output: N/A
• Output Impedance: 450 Ω
• S/N Ratio: 96 dB (A-Weighted, referred to 4V RMS Output)
• THD+N @ Rated Output: 0.02% (20 Hz - 20 kHz

Signal Processing

• Audio Resolution: 24 bit / 48 kHz
• Number of EQ Bands: 30 x 2 channels
• EQ Resolution: 1/3 octave (25 Hz - 20 kHz)
• Remote Level Control: Optional (DRC-100 or DRC-200)
• Remote Level Functions: Master Volume Control, Handsfree Optimization, LED Status Reporting (DRC-200 adds Subwoofer Level Control)

Physical Specifications

• Height (H): 1.85 in / 47 mm
• Width (W): 4.29 in / 109 mm
• Depth (D): 6.14 in / 156 mm
• Net Weight: 2.58 lb / 1.17 kg

JL Audio VX1000/5i 5-Channel Class D Amplifier with DSP

Designed to simplify great audio, every VXi amplifier combines our advanced NexD2™ switching amplifier technology with an integrated, full-featured digital signal processor.

Employing our second generation NexD2™ amplifier technology, the VX1000/5i efficiently powers a complete audio system. It can drive four main speakers with 75 W x 4 @ 4 ohms while also powering a subwoofer with up to 600W @ 2 ohms. Bridging the main channels converts it into a very powerful, 3-channel system amplifier with up to 200W x 2 @ 4 ohms on the main channels and 600W @ 2 ohms on the subwoofer channel.

The NexD2™ full-range technology in the main channels of this amplifier is DSP-controlled and features a reduced loop area design utilizing DirectFET™ outputs for outstanding fidelity, very low noise and exceptional efficiency. The subwoofer channel features an optimized low-frequency variant of the NexD2™ technology. The amplifier chassis is ultra-compact, with all connections on one side, to greatly simplify installation into tight spaces.

Instead of traditional control knobs and switches, all amplifier adjustments and DSP functionality are configured via a compatible external device (PC, Tablet or Smartphone), with the appropriate JL Audio TüN™ Software application installed.

Amplifier includes: Power Connector (for 2 AWG wire), Analog Input/Pre-Out Harness, Speaker Output Harness, Subwoofer Output Connector, 6 ft A/B USB Cable

Specifications

Rated Continuous (RMS) Power @ 14.4 V
Main Channels @ 4 Ω: 75 W RMS x 4
Main Channels @ 2 Ω: 100 W RMS x 4
Main Channels - Bridged @ 4Ω: 200 W RMS x 2
Subwoofer Channel @ 4 Ω: 400 W RMS x 1
Subwoofer Channel @ 3 Ω: 500 W RMS x 1
Subwoofer Channel @ 2 Ω: 600 W RMS x 1
Subwoofer Channel @ 1.5 Ω: N/A

Rated Continuous (RMS) Power @ 12.5 V
Main Channels @ 4 Ω: 60 W RMS x 4
Main Channels @ 2 Ω: 90 W RMS x 4
Main Channels - Bridged @ 4Ω: 180 W RMS x 2
Subwoofer Channel @ 4 Ω: 360 W RMS x 1
Subwoofer Channel @ 3 Ω: 480 W RMS x 1
Subwoofer Channel @ 2 Ω: 600 W RMS x 1
Subwoofer Channel @ 1.5 Ω: N/A

General Specifications
Frequency Response (Main Channels): 12 Hz - 24 kHz (+0, -1dB)
Frequency Response (Subwoofer Channel): 12 Hz - 1 kHz (+0, -1dB)
S/N Ratio, referred to highest rated power (Analog Inputs - Main Channels): 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to highest rated power (Analog Inputs - Main Channels): 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to highest rated power (Analog Inputs - Subwoofer Channel): 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W (Analog Inputs - Main Channels): 80 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W (Analog Inputs - Subwoofer Channel): 72 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to highest rated power (Digital Inputs - Main Channels): 100 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to highest rated power (Digital Inputs - Subwoofer Channel): 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W (Digital Inputs - Main Channels): 81 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W (Digital Inputs - Subwoofer Channel): 73 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
Damping Factor @ 2 Ω: >50 / 50 Hz
Damping Factor @ 4 Ω: >150 / 50 Hz
THD+N @ Rated Power (Main Channels): <1% @ 2 Ω per Ch.
THD+N @ Rated Power (Subwoofer Channels): <1% @ 2 Ω per Ch.
Input Voltage Range @ RCA Inputs: 200 mV - 16 V RMS
Min.Copper Power / Ground Wire Gauge: 4 AWG wire
Fuse Rating: 80 A (AFS, AGU or MaxiFuse™)

Physical Specifications
Height (H): 2.12 in / 54 mm
Width (W): 11.32 in / 287 mm
Depth (D): 6.62 in / 168 mm
Net Weight: 6.45 lb / 2.93 kg

JL Audio VX1000/1i

Monoblock Amplifier with Integrated DSP VXi amplifiers combine JL Audio’s advanced amplifier technology with a powerful digital signal processor, all within a compact and beautiful package that is easy to install and offers unprecedented tuning power and flexibility. At the heart of each VXi amplifier is a customized, triple-core AKM® DSP engine. This powerful DSP not only enables powerful tuning capabilities, but it also helps to improve amplifier audio performance by acting as a master clock for the full-range audio amplifier sections. Further amplifier performance gains have been achieved via minimum loop area output designs, DirectFET® output devices and closely coupled output capacitor banks. The result is a new level of Class D amplifier performance, with outstanding efficiency, reliable power delivery and world-class audio quality. The triple-core DSP engine has ample power to enable a full suite of powerful signal processing functions. These include powerful input switching, routing and mixing that allow a wide range of sources and configurations. Also included for each amplifier output channel and the analog pre-outs: high pass and low pass filters, delay, all-pass filter, polarity and output level trim. Optical, digital pre-outs feature the ability to EQ and level control the digital stream. Instead of using traditional control knobs and switches, VXi amplifiers are easily configured from the driver’s seat, using JL Audio’s free TüN™ software on a compatible computer, tablet or smartphone. Users can define up to six active preset tunings that can be called up at the push of a button using one of the compatible DRC controllers (sold separately).

Overview

Designed to simplify great audio, every VXi amplifier combines our advanced NexD2™ switching amplifier technology with an integrated, full-featured digital signal processor. The VX1000/1i monoblock subwoofer amplifier outputs up to 600 watts into 4 ohms, or a jaw-dropping 1000 watts into 2 ohms. A specialized, low-frequency version of our NexD2™ amplifier technology delivers rock-solid bass performance and fidelity, with outstanding efficiency. Compact dimensions with all connections placed on one side, via mating plugs, greatly simplify installation into tight spaces. Instead of traditional control knobs and switches, all amplifier adjustments and DSP functionality are configured via a compatible external device (PC, Tablet or Smartphone), with the appropriate JL Audio TüN™ Software application installed. Amplifier includes: Power Connector (for 2 AWG wire), Analog Input/Pre-Out Harness, Subwoofer Output Connector, 6 ft A/B USB Cable

Features

TüN™ Software Applications Intuitive setup and tuning, all at your fingertips. Automatically recognizes connected amplifier and displays appropriate interface. TüN™ is available for download for free in a variety of applications, for computers and most handheld devices. Unprecedented, Onboard DSP Tuning Power

• Premium, triple-core AKM® DSP with an optimized configuration, developed in collaboration with AKM®
• Hi-Res audio processing at 24 bit/96 kHz
• High-performance AKM® A/D and D/A converters
• 10 Bands of fully parametric EQ, per output channel, including pre-outs
• Shelving EQ option for Band 1 and Band 10
• High-Pass & Low-Pass Filters for each output channel, with selectable alignments and slopes:
• Linkwitz-Riley: 12, 24, 48 dB/octave
• Butterworth: 6, 12, 18, 24, 36, 48 dB/octave
• Signal Delay in 0.01 millisecond steps (equivalent to 1/8-inch, 3 mm)
• All-Pass Filter (Phase EQ), with variable "Q" and corner frequency
• Polarity Reversal (0 or 180 deg.)
• Output Level Trim in 0.1 dB steps

NexD2™ Switching Amplifier Technology

• Our latest generation of high-speed switching technology delivers superb low frequency power and efficiency.
• Specially optimized for subwoofer applications

Ultra-Versatile Analog and Digital Inputs

• High-performance, differential-balanced analog inputs for outstanding noise rejection
• Accepts speaker level signals from 200 mV, up to 16V RMS, including those from many factory systems
• Optical Digital (Toslink) input permits direct connection of S/PDIF digital sources, bypassing A/D converter. Accepts up to 24 bit/192 kHz input.
• Independently configurable RCA analog and digital pre-outs (24 bit/96 kHz)
• Automatic turn-on options via Signal-Sensing or DC-Offset sensing

Functional Compact Chassis Design

• Solid cast alloy main unibody and bottom plate deliver superb EMI performance and shielding
• All connections utilize compact mating connectors for maximum integrity and fitment into tight spaces.
• Configurable LED logo ring displays status and can display audio preset color code or user-defined color
• Logo badge can be oriented in 90 degree increments
• Corner caps engineered to conceal mounting holes and hardware

JLid™ System Command and Control with Networking Capabilities JL Audio's digital protocol provides control interface and communication between VXi amplifiers and optional JLid™ accessories, including:

• DRC-100/DRC-200/DRC-205 (coming soon) Digital Remote Controllers: Offers convenient level and DSP preset control from the driver's seat.
• VXi-BTC Bluetooth® Communicator (coming soon): Permits wireless configuration of VXi amplifiers using your compatible Apple® or Android® device.
• VXi-HUB Optical Network Hub (coming soon): Provides network connectivity for up to five slave VXi amplifiers, allowing synchronization of DRC controllers and DSP presets. Up to two VXi-HUBs can be daisy-chained to network up to ten VXi amplifiers.

Specifications

Rated Continuous (RMS) Power @ 14.4 V

• @ 4 Ω 600 W RMS x 1
• @ 3 Ω 800 W RMS x 1
• @ 2 Ω 1000 W RMS x 1
• @ 1.5 Ω N/A

Rated Continuous (RMS) Power @ 12.5 V

• @ 4 Ω 500 W RMS x 1
• @ 3 Ω 650 W RMS x 1
• @ 2 Ω 800 W RMS x 1
• @ 1.5 Ω N/A

General Specifications

• S/N Ratio, referred to highest rated power (Analog Inputs) 87 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to 1 W (Analog Inputs) 60 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to highest rated power (Digital Inputs) 87 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to 1 W (Digital Inputs) 56 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• Damping Factor @ 4 Ω >400 / 50 Hz
• Damping Factor @ 2 Ω >300 / 50 Hz
• Input Voltage Range @ RCA Inputs 200 mV - 16 V RMS
• Min.Copper Power / Ground Wire Gauge 4 AWG wire
• Fuse Rating 80 A (AFS, AGU or MaxiFuse™)
• S/N Ratio, referred to highest rated power (Analog Inputs) 87 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to 1 W (Analog Inputs) 60 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to highest rated power (Digital Inputs) 87 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to 1 W (Digital Inputs) 56 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• Damping Factor @ 4 Ω >400 / 50 Hz
• Damping Factor @ 2 Ω >300 / 50 Hz
• Input Voltage Range @ RCA Inputs 200 mV - 16 V RMS
• Min.Copper Power / Ground Wire Gauge 4 AWG wire
• Fuse Rating 80 A (AFS, AGU or MaxiFuse™)

Physical Specifications

• Height (H) 2.12 in / 54 mm
• Width (W) 11.32 in / 287 mm
• Depth (D) 6.62 in / 168 mm
• Net Weight 6.55 lb / 2.95 kg
• Height (H) 2.12 in / 54 mm
• Width (W) 11.32 in / 287 mm
• Depth (D) 6.62 in / 168 mm
• Net Weight 6.55 lb / 2.95 kg

JL Audio VX600/6i

6 Channel Reference Grade Amplifier with Integrated DSP VXi amplifiers combine JL Audio’s advanced amplifier technology with a powerful digital signal processor, all within a compact and beautiful package that is easy to install and offers unprecedented tuning power and flexibility. At the heart of each VXi amplifier is a customized, triple-core AKM® DSP engine. This powerful DSP not only enables powerful tuning capabilities, but it also helps to improve amplifier audio performance by acting as a master clock for the full-range audio amplifier sections. Further amplifier performance gains have been achieved via minimum loop area output designs, DirectFET® output devices and closely coupled output capacitor banks. The result is a new level of Class D amplifier performance, with outstanding efficiency, reliable power delivery and world-class audio quality. The triple-core DSP engine has ample power to enable a full suite of powerful signal processing functions. These include powerful input switching, routing and mixing that allow a wide range of sources and configurations. Also included for each amplifier output channel and the analog pre-outs: high pass and low pass filters, delay, all-pass filter, polarity and output level trim. Optical, digital pre-outs feature the ability to EQ and level control the digital stream. Instead of using traditional control knobs and switches, VXi amplifiers are easily configured from the driver’s seat, using JL Audio’s free TüN™ software on a compatible computer, tablet or smartphone. Users can define up to six active preset tunings that can be called up at the push of a button using one of the compatible DRC controllers (sold separately).

Overview

Designed to simplify great audio, every VXi amplifier combines our advanced NexD2™ switching amplifier technology with an integrated, full-featured digital signal processor. With our second-generation NexD2™ technology, the VX600/6i full-range amplifier outputs up to 75 watts per channel into 4 ohms, or 100 watts into 2 ohms. It can also be bridged into 4 ohms, producing up a rock-solid 200 W x 3. The NexD2™ full-range technology in this amplifier is DSP-controlled and features a reduced loop area design utilizing DirectFET™ outputs for outstanding fidelity, very low noise and exceptional efficiency. The amplifier chassis is ultra-compact, with all connections on one side, to greatly simplify installation into tight spaces. Instead of traditional control knobs and switches, all amplifier adjustments and DSP functionality are configured via a compatible external device (PC, Tablet or Smartphone), with the appropriate JL Audio TüN™ Software application installed. Amplifier includes: Power Connector (for 4 AWG wire), Analog Input/Pre-Out Harness, Speaker Output Harness, 6 ft A/B USB Cable

Features

TüNTM Software Applications Intuitive setup and tuning, all at your fingertips. Automatically recognizes connected amplifier and displays appropriate interface. TüN™ is available for download for free in a variety of applications, for computers and most handheld devices. Unprecedented, Onboard DSP Tuning Power

• Premium, triple-core AKM® DSP with an optimized configuration, developed in collaboration with AKM®
• Hi-Res audio processing at 24 bit/96 kHz
• High-performance AKM® A/D and D/A converters
• 10 Bands of fully parametric EQ, per output channel, including pre-outs
• Shelving EQ option for Band 1 and Band 10
• High-Pass & Low-Pass Filters for each output channel, with selectable alignments and slopes:
• Linkwitz-Riley: 12, 24, 48 dB/octave
• Butterworth: 6, 12, 18, 24, 36, 48 dB/octave
• Signal Delay in 0.01 millisecond steps (equivalent to 1/8-inch, 3 mm)
• All-Pass Filter (Phase EQ), with variable "Q" and corner frequency
• Polarity Reversal (0 or 180 deg.)
• Output Level Trim in 0.1 dB steps

NexD2TM Switching Amplifier Technology

• Our latest generation of high-speed switching technology delivers superb full-range power, fidelity and efficiency.
• DSP acts as central clock for all channels to improve audio quality and reduce noise.

Ultra-Versatile Analog and Digital Inputs

• High-performance, differential-balanced analog inputs for outstanding noise rejection
• Accepts speaker level signals from 200 mV, up to 16V RMS, including those from many factory systems
• Optical Digital (Toslink) input permits direct connection of S/PDIF digital sources, bypassing A/D converter. Accepts up to 24 bit/192 kHz input.
• Independently configurable RCA analog and digital pre-outs (24 bit/96 kHz)
• Automatic turn-on options via Signal-Sensing or DC-Offset sensing

Functional Compact Chassis Design

• Solid cast alloy main unibody and bottom plate deliver superb EMI performance and shielding
• All connections utilize compact mating connectors for maximum integrity and fitment into tight spaces.
• Configurable LED logo ring displays status and can display audio preset color code or user-defined color
• Logo badge can be oriented in 90 degree increments
• Corner caps engineered to conceal mounting holes and hardware

JLidTM System Command and Control with Networking Capabilities JL Audio's digital protocol provides control interface and communication between VXi amplifiers and optional JLidTM accessories, including:

• DRC-100/DRC-200/DRC-205 (coming soon) Digital Remote Controllers: Offers convenient level and DSP preset control from the driver's seat.
• VXi-BTC Bluetooth® Communicator (coming soon): Permits wireless configuration of VXi amplifiers using your compatible Apple® or Android® device.
• VXi-HUB Optical Network Hub (coming soon): Provides network connectivity for up to five slave VXi amplifiers, allowing synchronization of DRC controllers and DSP presets. Up to two VXi-HUBs can be daisy-chained to network up to ten VXi amplifiers.

Specifications

Rated Continuous (RMS) Power @ 14.4 V

• @ 4 Ω 75 W RMS x 6
• @ 2 Ω 100 W RMS x 6
• Bridged @ 4Ω 200 W RMS x 3

Rated Continuous (RMS) Power @ 12.5 V

• @ 4 Ω 60 W RMS x 6
• @ 2 Ω 90 W RMS x 6
• Bridged @ 4Ω 180 W RMS x 3

General Specifications

• Frequency Response 12 Hz - 24 kHz (+0, -1dB)
• S/N Ratio, referred to highest rated power (Analog Inputs) 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to 1 W (Analog Inputs) 80 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to highest rated power (Digital Inputs) 99 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• S/N Ratio, referred to 1 W (Digital Inputs) 80 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
• Damping Factor @ 4 Ω >100 / 50 Hz
• Damping Factor @ 2 Ω >50 / 50 Hz
• THD+N @ Rated Power <1% @ 2 Ω per Ch.
• Input Voltage Range @ RCA Inputs 200 mV - 16 V RMS
• Min.Copper Power / Ground Wire Gauge 4 AWG wire
• Fuse Rating 50 A (AFS, AGU or MaxiFuse™)

Physical Specifications

• Height (H) 2.12 in / 54 mm
• Width (W) 9.81 in / 250 mm
• Depth (D) 6.62 in / 168 mm
• Net Weight 5.55 lb / 2.5 kg
