Experience the impressive power and exceptional performance of the Next-Gen R-Series R2-A75M Mono Amplifier, now featuring a more compact design. The R2-A75M features a reduced footprint that’s 15% smaller than the previous model (R-A75M), making it easier than ever to install in most vehicle applications while still getting the same powerhouse performance.
Features 750W Mono Amplifier Alpine’s Class D Amplifier Circuit Reduced Footprint (15% smaller compared to the previous R-A75M model) One-Sided Terminal Layout Top Panel Sound Controls Integrated Mounting Feet for Simple Installation Optional Remote Bass Knob Compatible (required RUX-KNOB.2 or RUX-H01, sold separately)
Elevate your Audio Elevate your audio with the Alpine R2-A75M Mono Amplifier - delivering powerful 750W performance in a sleek, compact design. Built with Alpine's cutting-edge Class D Amplifier Circuit, this next-generation R-Series amp offers exceptional sound quality and efficiency, making it the perfect addition to any car audio system.
Reduced Footprint The R2-A75M features a reduced footprint that’s 15% smaller than the previous model (R-A75M), making it easier than ever to install in most vehicle applications while still getting the same powerhouse performance.
Convenience & Simplicity The R2-A75M features intentional design choices that prioritize convenience and simplicity. All speaker connections are consolidated on one side of the device for easy access, while the amplifier controls have been relocated to the top under a removable plate, allowing for quick adjustments to gain and crossover controls. The amplifier's chassis also includes integrated mounting "feet" to streamline the installation process.
Specifications Dimensions: 11.1” W x 2.17” H x 6.5” D Weight: 7 lbs, 10 oz Power Rating: 14.4V, ≤ 1% THD +N Power Output: 500W RMS x 1 @ 4Ω, 750W RMS x 1 @ 2Ω S/N Ratio: >75dB Frequency Response: 10Hz – 400Hz Damping Factor: >250 CTA-2006-D Certification
What's in the Box (x1) R2-A75M Mono Amplifier Owner’s Manual “Birth Sheet” that certifies by measurement the actual power of the amplifier in the box (x4) Screws for amplifier mounting to the vehicle (x3) Allen wrench for amplifier connection and installation (2mm, 2.5mm, 3mm) Alpine Registration Card Alpine Limited Warranty Sheet Installation Guide
With the highest quality music streaming available on the market, Alpine Status delivers a superior level of audio performance that will take your music to a whole new level.
Features
800W Mono Amplifier High-Efficiency Digital Circuit Design Alpine’s Dual Negative Feedback Control Circuit High Bandwidth Amplifier Alpine’s Premium Class D Circuit Design Copper-plated chassis Black circuit board One-sided terminal layout Top panel sound controls Quick connect power and speaker terminals Optional Remote bass knob compatible (requires RUX-KNOB.2 or RUX-H01, sold separately)
Superior Sound Using expertise gleaned from over five decades of crafting premium car audio products and trickle-down engineering and design from the Ultra Hi-Res AlpineF#1Status system technologies, the Alpine Status System features exceptional tooling and rich build quality for the best possible sound reproduction. Each component was hand-picked from the highest-quality materials for the highest in-class audio performance, that when used as a complete system, can achieve 192kHz/24Bit playback.
Impressive Output Powering a Hi-Res sound system without contributing noise during playback requires efficiency and precision and the HDA-M80 was intentionally designed to provide impressive power output to the system while ensuring the purest audio performance. The amplifier’s wide dynamic range capability provides impressive output in a compact chassis that fits most vehicle applications.
Precise Sound Reproduction The HDA-M80 features a high-efficiency digital circuit design that ensures ultra-low distortion levels for precise sound reproduction and superb sound quality. Intentional designs, like a copper-plated chassis and black circuit board, bring the signal-to-noise ratio up to 83dB and minimize noise and distortion during playback for complete music fidelity that’s true to the original source.
Incredible Reliability Featuring technology unique to Alpine, the amplifier features Alpine’s dual negative feedback control circuit to improve linearity for the most accurate sound amplification. This technology also stabilizes the amplifier output while driving the subwoofers for ultimate reliability.
Easy Installation The HDA- M80 features Alpine’s quick-connect power and speaker connectors for quick and safe installation. The one-sided terminal layout and top-panel sound controls give the user quick access to controls on the amplifier.
Optimized for a Full System The Alpine Status System is sold separately and can be used to build a custom sound system. Three sets of true 4V preamp outputs are included to add additional amplifiers if more power is needed. For best results, install the complete Alpine Status system together as a full system to achieve the highest in-class audio performance only second to the Ultra High-Resolution AlpineF#1System.
Specifications
Dimensions: 11.4375” x 7.5” x 2.125” Power Rating: (14.4V, ≤1.0% THD+N) 800W x 1 @ 2Ω 500W x 1 @ 4Ω THD+N: 0.02% (10W into 4ohm) S/N Ratio: 83dB (1W into 4ohm) Frequency response: 8-400Hz (-3dB) Damping factor: 1500 Selectable input level – HI/LO Variable High pass / Low pass crossover Variable Subsonic filter Bass EQ (0 to +12dB, Variable) Auto-turn on with remote sensing
What's in the Box
HDA-M80 Mono Amplifier Owner’s manual “Birth sheet” that certifies by measurement the actual power of the amplifier in the box 4 Screws for amplifier mounting to vehicle 2pcs. Mount bracket w/ 4 Screws for attachment to amplifier 3pcs. Allen wrench for amplifier connection & installation – Sizes: 2mm/2.5mm/4mm 1pc. Quick connector block for Power/Ground/Remote wires 1pc. Quick connector block for Speaker wires
Monoblock Amplifier with Integrated DSP
VXi amplifiers combine JL Audio’s advanced amplifier technology with a powerful digital signal processor, all within a compact and beautiful package that is easy to install and offers unprecedented tuning power and flexibility.
At the heart of each VXi amplifier is a customized, triple-core AKM® DSP engine. This powerful DSP not only enables powerful tuning capabilities, but it also helps to improve amplifier audio performance by acting as a master clock for the full-range audio amplifier sections. Further amplifier performance gains have been achieved via minimum loop area output designs, DirectFET® output devices and closely coupled output capacitor banks. The result is a new level of Class D amplifier performance, with outstanding efficiency, reliable power delivery and world-class audio quality.
The triple-core DSP engine has ample power to enable a full suite of powerful signal processing functions. These include powerful input switching, routing and mixing that allow a wide range of sources and configurations. Also included for each amplifier output channel and the analog pre-outs: high pass and low pass filters, delay, all-pass filter, polarity and output level trim. Optical, digital pre-outs feature the ability to EQ and level control the digital stream.
Instead of using traditional control knobs and switches, VXi amplifiers are easily configured from the driver’s seat, using JL Audio’s free TüN™ software on a compatible computer, tablet or smartphone. Users can define up to six active preset tunings that can be called up at the push of a button using one of the compatible DRC controllers (sold separately).
Overview
Designed to simplify great audio, every VXi amplifier combines our advanced NexD2™ switching amplifier technology with an integrated, full-featured digital signal processor.
The VX1000/1i monoblock subwoofer amplifier outputs up to 600 watts into 4 ohms, or a jaw-dropping 1000 watts into 2 ohms. A specialized, low-frequency version of our NexD2™ amplifier technology delivers rock-solid bass performance and fidelity, with outstanding efficiency. Compact dimensions with all connections placed on one side, via mating plugs, greatly simplify installation into tight spaces.
Instead of traditional control knobs and switches, all amplifier adjustments and DSP functionality are configured via a compatible external device (PC, Tablet or Smartphone), with the appropriate JL Audio TüN™ Software application installed.
Amplifier includes: Power Connector (for 2 AWG wire), Analog Input/Pre-Out Harness, Subwoofer Output Connector, 6 ft A/B USB Cable
Features
TüN™ Software Applications
Intuitive setup and tuning, all at your fingertips. Automatically recognizes connected amplifier and displays appropriate interface. TüN™ is available for download for free in a variety of applications, for computers and most handheld devices.
Unprecedented, Onboard DSP Tuning Power
Premium, triple-core AKM® DSP with an optimized configuration, developed in collaboration with AKM®
Hi-Res audio processing at 24 bit/96 kHz
High-performance AKM® A/D and D/A converters
10 Bands of fully parametric EQ, per output channel, including pre-outs
Shelving EQ option for Band 1 and Band 10
High-Pass & Low-Pass Filters for each output channel, with selectable alignments and slopes:
Linkwitz-Riley: 12, 24, 48 dB/octave
Butterworth: 6, 12, 18, 24, 36, 48 dB/octave
Signal Delay in 0.01 millisecond steps (equivalent to 1/8-inch, 3 mm)
All-Pass Filter (Phase EQ), with variable "Q" and corner frequency
Polarity Reversal (0 or 180 deg.)
Output Level Trim in 0.1 dB steps
NexD2™ Switching Amplifier Technology
Our latest generation of high-speed switching technology delivers superb low frequency power and efficiency.
Specially optimized for subwoofer applications
Ultra-Versatile Analog and Digital Inputs
High-performance, differential-balanced analog inputs for outstanding noise rejection
Accepts speaker level signals from 200 mV, up to 16V RMS, including those from many factory systems
Optical Digital (Toslink) input permits direct connection of S/PDIF digital sources, bypassing A/D converter. Accepts up to 24 bit/192 kHz input.
Independently configurable RCA analog and digital pre-outs (24 bit/96 kHz)
Automatic turn-on options via Signal-Sensing or DC-Offset sensing
Functional Compact Chassis Design
Solid cast alloy main unibody and bottom plate deliver superb EMI performance and shielding
All connections utilize compact mating connectors for maximum integrity and fitment into tight spaces.
Configurable LED logo ring displays status and can display audio preset color code or user-defined color
Logo badge can be oriented in 90 degree increments
Corner caps engineered to conceal mounting holes and hardware
JLid™ System Command and Control with Networking Capabilities
JL Audio's digital protocol provides control interface and communication between VXi amplifiers and optional JLid™ accessories, including:
DRC-100/DRC-200/DRC-205 (coming soon) Digital Remote Controllers: Offers convenient level and DSP preset control from the driver's seat.
VXi-BTC Bluetooth® Communicator (coming soon): Permits wireless configuration of VXi amplifiers using your compatible Apple® or Android® device.
VXi-HUB Optical Network Hub (coming soon): Provides network connectivity for up to five slave VXi amplifiers, allowing synchronization of DRC controllers and DSP presets. Up to two VXi-HUBs can be daisy-chained to network up to ten VXi amplifiers.
Specifications
Rated Continuous (RMS) Power @ 14.4 V
@ 4 Ω 600 W RMS x 1
@ 3 Ω 800 W RMS x 1
@ 2 Ω 1000 W RMS x 1
@ 1.5 Ω N/A
Rated Continuous (RMS) Power @ 12.5 V
@ 4 Ω 500 W RMS x 1
@ 3 Ω 650 W RMS x 1
@ 2 Ω 800 W RMS x 1
@ 1.5 Ω N/A
General Specifications
S/N Ratio, referred to highest rated power (Analog Inputs) 87 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W (Analog Inputs) 60 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to highest rated power (Digital Inputs) 87 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W (Digital Inputs) 56 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
Damping Factor @ 4 Ω >400 / 50 Hz
Damping Factor @ 2 Ω >300 / 50 Hz
Input Voltage Range @ RCA Inputs 200 mV - 16 V RMS
Min.Copper Power / Ground Wire Gauge 4 AWG wire
Fuse Rating 80 A (AFS, AGU or MaxiFuse™)
S/N Ratio, referred to highest rated power (Analog Inputs) 87 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W (Analog Inputs) 60 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to highest rated power (Digital Inputs) 87 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W (Digital Inputs) 56 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
Damping Factor @ 4 Ω >400 / 50 Hz
Damping Factor @ 2 Ω >300 / 50 Hz
Input Voltage Range @ RCA Inputs 200 mV - 16 V RMS
With the highest quality music streaming available on the market, Alpine Status delivers a superior level of audio performance that will take your music to a whole new level.
Features
Hi-Res Audio Playback (192kHz/24Bit) 5-Channel Amplifier High-Efficiency Digital Circuit Design Alpine’s Dual Negative Feedback Control Circuit High Bandwidth Amplifier Alpine’s Premium Class D Circuit Design Copper-plated chassis Black circuit board One-sided terminal layout Top panel sound controls Quick connect power and speaker terminals Optional Remote bass knob compatible (requires RUX-KNOB.2 or RUX-H01, sold separately)
Superior Sound Using expertise gleaned from over five decades of crafting premium car audio products and trickle-down engineering and design from the Ultra Hi-Res AlpineF#1Status system technologies, the Alpine Status System features exceptional tooling and rich build quality for the best possible sound reproduction. Each component was hand-picked from the highest-quality materials for the highest in-class audio performance, that when used as a complete system, can achieve 192kHz/24Bit playback.
Impressive Output Powering a Hi-Res sound system without contributing noise during playback requires efficiency and precision and the HDA-V90 was intentionally designed to provide impressive power output to the system while ensuring the purest audio performance. The amplifier’s wide dynamic range capability provides impressive output in a compact chassis that fits most vehicle applications.
Precise Sound Reproduction The HDA-V90 features a high-efficiency digital circuit design that ensures ultra-low distortion levels for precise sound reproduction and superb sound quality. Intentional designs, like a copper-plated chassis and black circuit board, bring the signal-to-noise ratio up to 87dB and minimize noise and distortion during playback for complete music fidelity that’s true to the original source.
Incredible Reliability Featuring technology unique to Alpine, the amplifier features Alpine’s dual negative feedback control circuit to improve linearity for the most accurate sound amplification. This technology also stabilizes the amplifier output while driving the speakers and subwoofers for ultimate reliability.
Easy Installation The HDA-V90 features Alpine’s quick-connect power and speaker connectors for quick and safe installation. The one-sided terminal layout and top-panel sound controls give the user quick access to controls on the amplifier.
Optimized for a Full System The Alpine Status System is sold separately and can be used to build a custom sound system. Three sets of true 4V preamp outputs are included to add additional amplifiers if more power is needed. For best results, install the complete Alpine Status system together as a full system to achieve the highest in-class audio performance only second to the Ultra High-Resolution AlpineF#1System.
Specifications
Dimensions: 11.4375” x 7.5” x 2.125” Power Rating: (14.4V, ≤1.0% THD+N) 75W x 4 + 300W x 1 @ 4Ω 100W x 4 + 500W x 1 @ 2Ω Bridged: 200W x 2 @ 4Ω (ch1/2, ch3/4 only) THD+N: 0.02% (10W into 4ohm) S/N Ratio: 87dB (1W into 4ohm) Frequency response: 8-60kHz (-3dB) Damping factor: 500 (ch1/2/3/4), 1000 (subwoofer) Selectable input level – HI/LO Selectable 2/4/6ch input Variable High pass / Low pass crossover Variable Subsonic filter (subwoofer) Bass EQ (0 to +12dB, Variable) Auto-turn on with remote sensing
What's in the Box
HDA-V90 5-Channel Amplifier Owner’s manual “Birth sheet” that certifies by measurement the actual power of the amplifier in the box 4 Screws for amplifier mounting to the vehicle 2pcs. Mount bracket w/ 4 Screws for attachment to the amplifier 3pcs. Allen wrench for amplifier connection & installation – Sizes: 2mm/2.5mm/4mm 1pc. Quick connector block for Power/Ground/Remote wires 3pcs. Quick connector block for Speaker wires
5-Channel Class D System Amplifier, 100 W x 4 + 500 W x 1
Thanks to its ability to act as a "one-box solution", the HD900/5 is ideal for installations where space is at a premium and sound quality is the paramount goal.
While extremely compact, this amazing amplifier will comfortably drive a complete high-performance car audio system: that is, four satellite speaker systems and a subwoofer system... with a very serious 900 watts of power!
Using our Single Cycle Control switching design and R.I.P.S. technology, the HD900/5 delivers 100 W x 4 to its four main channels, plus a very meaty 500 W to its subwoofer channel. Thanks to R.I.P.S., high power can be delivered over a wide range of load impedances, while the tight power supply regulation keeps distortion down, maximizing sound quality. From a pure sound quality perspective, we invite you to compare the real-world, in-car performance of this amplifier to any other amplifier on the market, of any type, at any price.
This amplifier features a brushed aluminum finish with black powder-coated cast alloy heat sinks and bottom panel. A black powder-coated, gasketed cover is also provided to protect the controls.
HD900/5 Five-Channel Class D System Amplifier Features:
HD900/5
Description:
Five-Channel Class D System Amplifier
Patented Technology:
Single Cycle Control™ (U.S. Patent #6,084,450*)
Inputs:
Three Stereo Pairs (Front, Rear and Sub)
Front Crossover:
Continously-variable (50 Hz - 500 Hz), selectable-slope (12 dB/octave Butterworth or 24 dB/octave Linkwitz-Riley) HP
Rear Crossover:
Continously-variable (50 Hz - 500 Hz), selectable-slope (12 dB/octave Butterworth or 24 dB/octave Linkwitz-Riley) HP
Notes: R.I.P.S. Regulated, Intelligent Power Supply, RealSink™ Heat-Management System, *Patented technology used under exclusive license for mobile audio from PowerPhysics, Inc. - Newport Beach, CA
HD900/5 Five-Channel Class D System Amplifier Specifications:
HD900/5
Rated Power Front Channels:
100W RMS x 2 @ 4O (11V - 14.5V) 75W RMS x 2 @ 1.5-3O (11V - 14.5V)
Rated Power Rear Channels:
100W RMS x 2 @ 4O (11V - 14.5V) 75W RMS x 2 @ 1.5-3O (11V - 14.5V)
Rated Power Subwoofer Channel:
500W RMS x 1 @ 1.5-4O (11V - 14.5V)
THD at Rated Power:
S/N Ratio (Front & Rear Channels):
>108.5 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio (Subwoofer Channel):
>95 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
Frequency Response (Front and Rear Channels):
12 Hz - 28 kHz (+0, -1dB)
Frequency Response (Subwoofer Channel):
12 Hz - 10 kHz (+0, -1dB)
Damping Factor (Front and Rear Channels):
>400 @ 4O per ch. / 50 Hz >200 @ 2O per ch. / 50 Hz
Damping Factor (Subwoofer Channel):
>800 @ 4O / 50 Hz >400 @ 2O / 50 Hz
Input Range:
Switchable from 200mV - 2V RMS (Low) to 800mV - 8V RMS (High)
Dimensions (L x W x H):
10.74 in. x 8.29 in. x 1.93 in. 273 mm x 211 mm x 49 mm (Width Measurement Includes Plugs)
