JL Audio M700/5 5-Channel Marine Amplifier

The M700/5 is ideal for a complete audiophile-grade, subwoofer + four satellite system, and it fits comfortably in just about any boat's weather-tight compartments. With this incredible little amplifier, you can drive two pairs of quality component speaker systems with plenty of clean power (75 W x 4 @ 4 Ohms), while also delivering a stout 300 W of power to a subwoofer system. The breakthrough that makes this much power possible in such a small chassis is our NexD™ switching design.

The M700/5 includes a 12 dB / octave high-pass filter for one main channel pair, a 12 dB octave high-pass or bandpass filter for the other main channel pair, plus a variable slope low-pass filter for its subwoofer channel. All three filters offer continuously variable cutoff frequency selection from 50-500 Hz. This amplifier's filters can also be configured as a true 3-way crossover, with a low-pass filter for the subwoofer channel, a bandpass filter on Ch. 3 & 4, and a high-pass filter on Ch. 1 & 2. An "x10" multiplier switch on the Ch. 1 & 2 high-pass filter allows its cutoff frequency to be adjusted from 50-500 Hz or 500-5000 Hz. With the addition of an HD-RLC remote level control (sold separately), the amplifier's subwoofer channel level or overall level can be directly controlled from a remote location.

This marine amplifier features white and gray powder-coat finishes, a gasketed cover for the controls and stainless steel hardware for durability in the marine environment.

Power Specifications - Rated Continuous (RMS) Power @ 12.5 V

Main Channels @ 4 Ohms: 60 W RMS x 4
Main Channels @ 2 Ohms: 90 W RMS x 4
Main Channels - Bridged @ 4Ohms: 180 W RMS x 2
Subwoofer Channel @ 4 Ohms: 180 W RMS x 1
Subwoofer Channel @ 3 Ohms: 240 W RMS x 1
Subwoofer Channel @ 2 Ohms: 300 W RMS x 1
Subwoofer Channel @ 1.5 Ohms: N/A

Specifications

Frequency Response (Main Channels): 12 Hz - 22 kHz (+0, -1dB)
Frequency Response (Subwoofer Channel): 10 Hz - 1 kHz (+0, -1dB)
S/N Ratio, referred to highest rated power (Main Channels): >104 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W: >84 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
Damping Factor @ 4 Ω: >150 / 50 Hz
Damping Factor @ 2 Ω: >75 / 50 Hz
THD+N @ Rated Power (Main Channels): <1% @ 2 Ω per Ch.
THD+N @ Rated Power (Subwoofer Channels): <1% @ 2 Ω per Ch.
Input Voltage Range @ RCA Inputs: 100 mV - 4 V RMS
Min.Copper Power / Ground Wire Gauge: 4 AWG wire
Fuse Rating: 60 A (AFS, AGU or MaxiFuse™)

Physical Specifications

Height (H): 2.05 in / 52 mm
Width (W): 10.23 in / 260 mm
Depth (D): 7.09 in / 180 mm
Net Weight: 6.15 lb / 2.79 kg
